Rhinoman Fitment Instructions for Ammo Box Rack Load Box- XP/XT/RinoLite
Fitment Instructions
for Rhinoman
Ammo Box Rack
Load Box
XTREME, XPEDITION & RHINOLITE
Fitment Kit Contents
Description
Quantity
Illustration
A. Load box assembly
1
Installation Time & Care Instructions
- Approx. 20 minutes.
⚠︎ Be aware of the edges on all sheet metal components and take extra care during handling.
⚠︎ Ensure that the area where the load will be installed is free from any obstructions.
Fitment Steps
Step 1
- Place the load box into the ammo box rack with the edges of the load box resting on the internal extrusion . Fig. 2.2.1
Step 2
- You have now successfully completed the fitment of your Rhinoman ammo box rack load box.
